2024 Diverge STR Pro

2024 Diverge STR Pro


Regular price R 155,000.00
Regular price R 155,000.00 Sale price R 155,000.00
Sale Sold out
Tax included. Shipping calculated at checkout.

Low stock: 1 left

Read More

With Future Shock suspension front and rear, the new Diverge STR delivers compliance without compromise. By suspending the rider—instead of the bike—Future Shock technology increases control and efficiency while decreasing fatigue, so you’ll be riding farther and faster over chunkier terrain than you believed possible. And the Diverge STR does this without the weight, sluggish pedal response, and inefficiency of other suspension systems. The Diverge STR Pro starts with our FACT 11r carbon frameset with front and rear Future Shock suspension. It’s built with SRAM’s Force eTap AXS Eagle groupset for fast, efficient shifting with a 10-50 cassette to ensure you have the gearing to tackle any ride. The bike rolls on the Roval Terra CL wheels with 42mm Tracer Pro tires. Terra carbon bars, an S-Works carbon seatpost, and Power Pro saddle complete the package making the Diverge STR the most capable Diverge ever.

  • By suspending the rider with damped, tunable travel—20mm front/30mm rear—Future Shock Technology absorbs bump forces to boost your control and capability while retaining the efficiency and responsiveness of a rigid frame. Because as far as power transfer goes, it is a rigid frame. Power to the pedals makes the bike jump like a scared cat. You’re efficient, you’re comfortable, you’re in control. Your bike is light, nimble, and responsive.
  • The new Diverge doesn’t just have gorgeous lines, it has perfect curves too. Future Shock Rear puts 30mm of rear travel in the ideal path to smooth out rough road. Its hydraulic damping controls travel to eliminate “bobbing” under power and ensure big hits never catapult you from the saddle, all without compromising fit or pedaling efficiency.
  • Born from decades of innovation and our Smoother is Faster philosophy, Future Shock was created to develop bikes that win on cobblestones, but it’s found its purest expression on gravel. It’s 20mm of adjustable, damped front travel that keeps you in control and on target, all while protecting your hands, arms, and shoulders from the battering.
  • More capability means more confidence, more confidence means more rides, more rides mean more fun, and it all starts at the contact patch. Nothing unlocks capability like tire clearance, and we’re feeling generous. 47mm on a 700c wheel and 2.1” on 650B. Diverge STR is the most capable gravel bike we’ve ever made, so it’s the most fun. We did the math.
View full details

Technical Specifications


Weight Size: 56

Weight: 9.18kg (20 lb, 3.8 oz)



Saddle: Body Geometry Power Pro, hollow titanium rails

Stem: Future Stem, Pro

Handlebars: Roval Terra, carbon, 103mm drop x 70mm reach x 12º flare

SeatPost: S-Works Carbon Seat Post, 20mm Offset

Seat Binder: Specialized Alloy, 33.3mm

Tape: Supacaz Super Sticky Kush



Fork: Future Shock 3.3 w/ Damper, Smooth Boot, FACT carbon, 12x100 mm thru-axle, flat-mount



Frame: Diverge FACT 11r carbon frameset with front and rear Future Shock suspension, SWAT™ Door integration, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc


Wheels & Tires

Inner Tubes: 700x28/38mm, 48mm Presta valve

Front Wheel: Roval Terra CL, 25mm internal width, 32mm depth, 24h, Tubeless ready, DT for Roval 350 hub, Centerlock disc, DT Swiss Competition Race spokes

Rear Wheel: Roval Terra CL, 25mm internal width, 32mm depth, 24h, Tubeless ready, DT for Roval 350 hub, Centerlock disc, DT Swiss Competition Race spokes

Front Tire: Tracer Pro 2BR, 700x42

Rear Tire: Tracer Pro 2BR, 700x42



SWAT: Integrated SWAT door, internal storage system



Bottom Bracket: SRAM DUB BSA 68

Shift Levers: SRAM Force eTap AXS

Crankset: SRAM Force 1x

Rear Derailleur: SRAM X01 Eagle AXS

Chain: SRAM X01 Eagle, 12-speed

Cassette: SRAM XG-1275 Eagle, 12-speed, 10-50t

Chainrings: 40T



Front Brake: SRAM Force, hydraulic disc, 160mm Paceline rotor

Rear Brake: SRAM Force, hydraulic disc, 160mm Paceline rotor


Crank Length165mm170mm172.5mm172.5mm175mm175mm
Handlebar Width380mm400mm420mm420mm440mm440mm
Stem Length60mm70mm80mm90mm100mm100mm
Saddle Width155mm155mm143mm143mm143mm143mm
Seatpost Length350mm350mm350mm350mm350mm350mm
Head Tube Length100mm100mm115mm130mm155mm182mm
Head Tube Angle70°70.5°71.25°71.75°71.75°71.75°
BB Height270mm265mm265mm265mm265mm265mm
BB Drop80mm85mm85mm85mm85mm85mm
Fork Length, Full390mm390mm390mm390mm390mm390mm
Fork Rake/Offset55mm55mm55mm55mm55mm55mm
Front Center607mm612mm619mm629mm645mm663mm
Chainstay Length429mm429mm429mm429mm429mm429mm
Top Tube Length, Horizontal527mm540mm556mm570mm586mm602mm
Bike Standover Height704mm730mm753mm778mm804mm833mm
Seat Tube Length390mm430mm470mm500mm530mm560mm
Seat Tube Angle74.5°74.25°74°74°74°74°
