Technical Specifications

E-Bike

Motor

All New Specialized 3.1 Motor, 101Nm torque, 666W power

Battery

840Wh battery

UI/Remote

All New MasterMind T3 Display System, 2.2" high resolution color screen, fully customizeable with Specialized app

Charger

Specialized 4amp charger

Frameset

Frame

All new Levo 4 frame, FACT 11m carbon chassis and rear-end, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, w/ SWAT storage, 150mm of travel, side entry battery, fork travel up to 180mm

Seat Binder

Alloy, 38.6mm

Suspension

Rear Shock

FOX FLOAT X Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever, LSR adjustment

Fork

FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm axle, 44mm offset, 160mm of travel

Brakes

Front Brake

SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm Rotor

Rear Brake

SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 200mm Rotor

Drivetrain

Shift Levers

SRAM AXS POD Controller

Rear Derailleur

SRAM S1000 Eagle Transmission, Wired SRAM AXS battery (powers AXS rear derailleur with integrated hot shoe directly off the Levo 4 main battery).

Cassette

SRAM 1270 Transmission Cassette, 12 Spd,10-52t

Chain

SRAM GX Eagle Transmission Flattop Chain

Crankset

SRAM S1000 Crankset, ISIS interface, Integrated Guard, 55mm Chainline, 155mm

Chainrings

SRAM T-type ring, 34T, 104 BCD, steel

Wheels & Tires

Rims

Specialized 29F/27.5R, hookless alloy, 30mm inner width, tubeless ready

Front Hub

Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h

Rear Hub

Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h

Spokes

DT Swiss Industry

Front Tire

Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"

Rear Tire

Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3"

Inner Tubes

Standard, Presta valve

Cockpit

Stem

Alloy Trail Stem, 35mm bar bore

Handlebars

Alloy handlebars, 35mm diameter, 8 degree back sweep, 6 degree up sweep, S2: 30mm rise, 780mm width, S3-S5: 40mm rise 800mm width

Grips

Specialized Trail Grips

Saddle

Bridge Comp, Hollow Cr-mo rails

SeatPost

Xfusion Manic, infinite adjustable, two bolt head, Remote SLR LE lever, 34.9, S2: 125mm, S3: 170mm, S4-S6: 190mm

Accessories

SWAT

SWAT internal downtube storage

Weight

Weight

24.41 kg (53 lb, 13.0 oz)

Weight Size

S4

* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
