E-Bike

Motor

Specialized 3.1 Motor, 101Nm torque, 666W power

Battery

Specialized Turbo X2 840Wh integrated battery pack

UI/Remote

Mastermind TCU, 2.2" high resolution screen, fully customizeable with Specialized app, works with Apple Find My

Charger

Specialized 4amp charger

Frameset

Frame

Levo 4 frame, 150mm travel, w/SWAT storage, side entry battery, fork travel up to 180mm, adjustable head angle, BB height, chainstay length Levo 4 frame, 150mm travel, w/SWAT storage*, side entry battery, fork travel up to 180mm, adjustable head angle, BB height, chainstay length *not available on S1

Seat Binder

Alloy, 38.6mm

Suspension

Rear Shock

Fox Float X Factory with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever, LSR adjustment, 210x55mm

Fork

Fox 38 Performance Elite series, 29", Grip X2 damper,15x110mm axle, 44mm offset, 160mm of travel

Brakes

Front Brake

SRAM Maven Silver, 4-piston caliper, hydraulic disc

Rear Brake

SRAM Maven Silver, 4-piston caliper, hydraulic disc

Drivetrain

Shift Levers

SRAM AXS POD Controller w/discrete clamp

Rear Derailleur

SRAM X0 Eagle Transmission

Cassette

SRAM XS 1295, 12 speed, 10-52

Chain

SRAM X0 12-Speed Chain

Crankset

SRAM XO Alloy crank, 155mm, ISIS interface

Chainrings

SRAM 34t T-Type chainring, 104 BCD, steel

Wheels & Tires

Front Tire

Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, TLR, 29x2.4"

Front Wheel

Traverse HD Carbon 29" Rim, DT Swiss 350, 15x110mm, 28h

Rear Tire

Butcher, GRID GRAVITY Casing, Gripton T9 compound, TLR, 27.5x2.4

Rear Wheel

Traverse HD 27.5" carbon rim, DT Swiss 350, XD freehub body, 12x148mm, 28h

Inner Tubes

Standard, Presta Valve

Cockpit

Stem

Industry 9 Mountain stem, 35mm clamp, 40mm length

Handlebars

Race Face Era Carbon Handlebars, 35mm clamp, back-sweep 8-degrees, up-sweep 5 degrees, 800mm width, S1/S2: 40mm rise, S3-S6: 55mm rise

Grips

Deity Lockjaw Grips

Saddle

Bridge Expert with MIMIC, Hollow Ti rails

SeatPost

Bike Yoke Revive Max 3.0, 34.9, S2:125mm, S3:160mm, S4: 185mm, S5/S6:213mm

Accessories

SWAT

SWAT Internal downtube storage

Product Details

Compliance Certification

As applicable, certified to UL 2849 (e-system) and/or UL 2271 (battery) by UL Solutions and/or SGS.
For information on lithium-ion battery standards and regulations in New York City, visit: www.nyc.gov/fdny/batteries

Weight

Weight

23.94 kg (52 lb, 12.5 oz)

Weight Size

S4

* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
