2025 Turbo Levo Comp Carbon

2025 Turbo Levo Comp Carbon

95225-5002

R 149,000.00
R 149,000.00 R 149,000.00
Sale Sold out
Tax included. Shipping calculated at checkout.
Color
Size

Out of stock

Read More

The all-new Levo delivers the unbelievable power to ride more trails through an unequaled combination of ride quality, usable power, and ride anywhere range. It’s the distillation, application, and amplification of a 40-year obsession with creating the world’s best riding mountain bikes. Since its introduction, Levo has set the bar every other e-MTB aims for, and the new Levo raises that bar again.

It starts with our Turbo Full Power 2.2 motor and Turbo Connect Unit (TCU), which provide Levo with a smooth and seamless amplification of your efforts—4x you power that lets you choose where to ride, and when you want to do it. Levo also shatters limitations when it comes to range, amplifying your effort for up to five hours of trail time. Now you can ride farther, and explore more, than ever before. And the optimized chassis boasts 150mm of custom-tuned rear suspension and adjustable geometry that delivers a stable and natural ride like no other. Because at the end of the day, it’s the ride that matters. Believe it.

More climbing, more descending, more miles, more fun. Spec’d with a no-fuss SRAM GX drivetrain, trail-taming FOX suspension, and a lightweight, durable alloy wheelset, the all-new Turbo Levo delivers more of everything that you love about trail riding.

  • Levo’s fully integrated Turbo Full Power 2.2 motor, 700Wh battery, and advanced MasterMind Turbo Control Unit deliver category-leading 90 Nm of torque and 565 watts of power for up to five hours of ride time, empowering you to ride farther and faster than ever before.
  • The MasterMind Turbo Control Unit is your information hub with customizable display fields, including the exact percentage of battery level, and it features our all-new MicroTune function to adjust power delivery in 10% increments, so you get exactly the support you need to experience precisely the ride you want.
  • A dedicated mixed-wheel size design with a 27.5 wheel in the back and 29 up front delivers a nimble ride that carves circles around other full-power e-MTBs. A generous cockpit centers you on the bike, optimizing traction and corner control. The low bottom bracket, slack headtube angle and reduced fork offset keep things stable in the rough.
  • Levo offers six distinct geometry settings, allowing you to easily dial-in its performance for any riding style andany terrain. Head tube angle can be adjusted between 63- and 65.5-degrees. Bottom bracket height can be fine-tuned up or down by 7mm.
  • Levo’s 150mm of rear travel is supple on small bumps, devours square-edged hits without a twitch, eats massive G-outs for breakfast, yet still offers amazing pedal response and delivers your power to the ground with total efficiency.
  • The Levo’s S-Sizing is based on what matters—rider size and style, not inseam. Six sizes, all with similar headtube lengths and standover, allow you to choose the size that best suits your individual style. Smaller S-Size numbers are going to be nimble and more flickable, while bigger S-Sizes deliver more stability and a roomier ride.
View full details

Technical Specifications

E-bike

Wiring Harness: Custom Specialized wiring harness

Charger: Custom charger, 42V4A w/ Rosenberger plug, 100-240V

Motor: Specialized 2.2 Custom Rx Trail Tuned Motor

Battery: Specialized M3-700, Integrated battery, 700Wh

UI/Remote: Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, ANT+/Bluetooth®, w/Handlebar remote



Cockpit

Stem: Alloy Trail Stem, 35mm bar bore

Saddle: Bridge Comp, Hollow Cr-mo rails, 155/143mm

Handlebars: 6061 mtn bars, 35mm diameter, 8 degree back sweep, 6 degrees up sweep, 800mm width. S1/S2: 30mm rise, S3-S6: 40mm rise

Grips: Specialized Trail Grips

SeatPost: X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4/S5: 170mm, S6: 190mm



Frameset

Seat Binder: Alloy, 38.6mm

Frame: FACT 11m full carbon, 29" front wheel, 27.5" rear wheel, full internal cable routing, 148mm spacing, fully sealed cartridge bearings, 150mm of travel, geo adjust head tube, geo adjust horst pivot



Suspension

Fork: Fox 36 Rhythm, 29", S2-S6: 160mm S1: 150mm, Grip damper

Rear Shock: FOX FLOAT X Performance, LSR, 2-position lever, 55x210mm



Brakes

Front Brake: SRAM Maven Bronze, 220mm rotor, metallic pads

Rear Brake: SRAM Maven Bronze, 200mm rotor, metallic pads



Drivetrain

Crankset: Praxis forged M30, custom offset, 160mm

Chain: SRAM GX Eagle, 12-speed

Shift Levers: SRAM GX Eagle, trigger, 12-speed, single click

Chainrings: SRAM X-Sync Eagle, 104 BCD, 32T, steel

Rear Derailleur: Sram X01 Eagle, 12-speed

Cassette: Sram XG-1275, 12-speed, 10-52t



Wheels & tires

Rear Hub: Alloy, sealed cartridge bearings, 148mmx12mm thru-axle, 28h

Front Hub: Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h

Front Tire: Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"

Spokes: DT Swiss Industry

Rear Tire: Eliminator, GRID GRAVITY casing, GRIPTON® T9/T7 compound, 27.5x2.3"

Rims: Specialized 29, hookless alloy, 30mm inner width, tubeless ready

Inner Tubes: Standard, Presta Valve



Accessories

SWAT: SWAT CC steerer tube integrated tool with chain tool and link



Product details

Product ID: 274923



Weight

Weight: 23.17 kg (51 lb, 1.3 oz)

Weight Size: S4

Geometry


 		S1S2S3S4S5S6
Crank Length160160160160160160
Handlebar Width800800800800800800
Stem Length404040404040
Saddle Width155155143143143143
Seatpost Length100125150170170190
Stack605617626635644653
Reach412432452477502532
Headtube Length105105115125135145
Headtube Angle64.564.564.564.564.564.5
BB Height352350350350350350
BB Drop252727272727
Trail130130130130130130
Fork Length (full)557567567567567567
Fork Rake/Offset444444444444
Front Center738760784814843878
Chainstay Length442442442442442442
Wheelbase117912001225125512841318
Bike Standover Height752776783787788790
Seat Tube Length380390405425445465
Seat Tube Angle7877.276.776.276.276.2
Max Seatpost Insertion210220240255275295
Min Seatpost Insertion808080808080
